Empty and clean Legacy+ powder container (machine option)

Switch off at the main power switch.

Unlock and push at the bottom of the panel (1) to remove it.

Unplug the tube (2) from the mixer.

Turn the handle upwards (CCW) (3) to unlock the mixer (4).

Remove the mixer (4).

Remove the powder chute (5).

Remove the powder container lid (6).

Pull the container (7) and lift to remove it.

Disassemble the powder container.

1. Turn 90° to unlock the screw (8) (open position) and remove it.

2. Remove the divider (9).

3. Remove the two wheels (10) with their springs.



4. Turn (approximately 45°) to unlock the two powder outlets (11) and remove them.

5. Slide the container (12) backward and remove it.



6. Remove the two screws (13) and their guide (14).



Clean all parts with soft soap, rinse with water and dry with a soft cloth.

Assemble the powder container.

1. Put the two screws (13) with their guide (14) back in their original position.



2. Install and slide the container (12) back into its original position.

   	Note
   	Ensure that the container is properly locked in position.

3. Install and turn to lock the two powder outlets (11).



4. Put the two wheels (10) with their springs back in their original position.

5. Put the divider (9) back in its original position.

   	Note
   	Ensure that the wheels (10) are still correctly positioned. If not, adjust the divider (9) and the position of the wheels (10) to allow the screw (8) to be installed.

6. Install the screw (8) and turn it to lock it (closed position).



Reassemble in the reverse order.

	Note
	Make sure that the powder containers and powder chutes are perfectly dry before refilling with powder.
